Description
Specification (WS-C2960S-24TS-L)
WS-C2960S-24TS-L Specifications |
|
|
General Information |
|
| Manufacturer | Cisco |
| Product ID: | WS-C2960S-24TS-L |
| Product Description: | Cisco CAT2960S Stack 24 Gige-4 x SFP LAN Base |
| Product Type: | Ethernet Switch |
|
Marketing Information |
|
| The Cisco Catalyst 2960-S and 2960 Series Switches with LAN Base provide the performance, and availability that today’s small businesses demand, as well as the intelligence to support business applications and security services. Switches are a key component of your network foundation and can improve the availability of critical applications, while protecting business information. The Cisco Catalyst 2960-S and 2960 Series Switches are specifically designed for growing businesses that need to accommodate expanding services, and optimize network bandwidth and to assure the fast and reliable delivery of applications and services. | |
|
Interfaces/Ports |
|
| Number of Ports: | 24 |
| Gigabit Ethernet Port: | Yes |
| Interfaces/Ports: | 24 x RJ-45 10/100/1000Base-T Network LAN |
|
Media & Performance |
|
| Forwarding/Filtering Rate: | 41.7 Mpps |
| Switching Throughput: | 176 Gbps |
|
I/O Expansions |
|
| Number of Expansion Slots: | 5 |
| Expansion Slots: | (4 Total) SFP (mini-GBIC) Uplink |
| (1 Total) Stacking Module | |
|
Network & Communication |
|
| Layer Support: | 2 |
|
Management & Protocols |
|
| Manageable: | Yes |
| Management: | DHCP
QoS VLAN SNMP v1, v2, v3 Syslog CLI RMON CiscoWorks LAN Management Solution |
|
Memory |
|
| Standard Memory: | 128MB |
| Memory Technology: | DRAM |
| Flash Memory: | 64MB |
|
Software |
|
| Operating System: | Cisco IOS |
|
Power Description |
|
| Input Voltage: | 110 V AC |
| 220 V AC | |
| Input Voltage Range: | 100 V AC to 240 V AC |
| Power Source: | Power Supply |
| Redundant Power Supply: | Yes |
|
Physical Characteristics |
|
| Compatible Rack Unit: | 1U |
| Form Factor: | Rack-mountable |
| Stackable | |
| Dimensions: | 1.75″ Height x 17.50″ Width x 11.80″ Depth |
| Weight (Approximate): | 10 lb |
